Jinko Tiger Neo N-Type 565W–585W Mono-Facial Solar Panel
High-Efficiency N-Type Panel for Domestic and Commercial Solar Systems
This Mono-Facial panel (model: JKM565-585N-72HL4) delivers definitive, high-output performance. With a power range from 565W to 585W. It is built with advanced N-Type monocrystalline cells. This panel is tailored to work easily under all weather conditions and maintain strong output for years. It’s a good choice for homes, offices, farms, and industrial rooftops needing serious power without taking up too much space.
Key Highlights
Strong and Efficient
Maximum power up to 585W
Efficiency up to 22.65%
Designed with 144 half-cut cells (6×24) for better performance and shading tolerance.
Better Durability
Withstands wind loads up to 2400 Pa and snow loads up to 5400 Pa
Anti-PID performance for long-term stability
Built to handle -40°C to +85°C temperature swings
Trusted Warranty
12-year product warranty
30-year linear power warranty
Less than 0.40% annual degradation, you’ll still get over 87% output after 30 years
Why Choose the Jinko Tiger Neo N-Type?
If you’re planning a high-yield solar setup and want a panel that holds up in tough environments, this model fits the bill. With industry-leading warranties, strong performance under heat, and reliable power output, the Jinko 565–585W N-Type panel brings real value to any system.
Need help sizing your system or selecting the right panel model? Contact Beyond Green Solar, and we’ll walk you through it, step by step.
Applications
Large home solar installations
Commercial rooftops
Farm sheds and greenhouses
Off-grid solar setups with high energy demand
Industrial setups
Electrical Performance (STC)
Model
Power (Pmax)
Voltage (Vmp)
Current (Imp)
Efficiency (%)
JKM565N-72HL4
565W
41.92V
13.48A
21.87%
JKM570N-72HL4
570W
42.07V
13.55A
22.07%
JKM575N-72HL4
575W
42.22V
13.62A
22.26%
JKM580N-72HL4
580W
42.37V
13.69A
22.45%
JKM585N-72HL4
585W
42.52V
13.76A
22.65%
Technical Specs
Open-Circuit Voltage (Voc): Up to 51.16V
Short-Circuit Current (Isc): Up to 14.55A
Power Tolerance: 0~+3%
System Voltage: 1000/1500V DC
Max Series Fuse Rating: 25A
Temperature Coefficients:
Pmax: -0.29%/°C
Voc: -0.25%/°C
Isc: +0.045%/°C
Mechanical Details
Feature
Detail
Module Size
2278 × 1134 × 35 mm
Weight
28 KG
Front Glass
3.2 mm tempered, anti-reflective
Frame
Anodized aluminium alloy
Junction Box
IP68 rated
Output Cables
(+) 400mm, (–) 200mm (customizable)
Installation & Maintenance Tips
To get the most out of your Jinko Tiger Neo N-Type Solar Panels, follow these tips:
Install in a well-ventilated, shaded area to avoid overheating and ensure maximum performance.
Regularly clean the panels to remove dirt and debris that may block sunlight and reduce efficiency.
Check the inverter compatibility with your solar panel system before installation.
Inspect the system for any loose connections or damage to ensure reliable operation.
Monitor performance regularly to identify and resolve any issues early on.
Avoid excessive water exposure on the panels to maintain their longevity and functionality.
Need Help Choosing the Right Solar Panel for Your System?
Looking to optimize your solar setup with the perfect panel? The Jinko Tiger Neo N-Type 565W–585W panels are an excellent choice for high-performance solar energy generation. Need help sizing your system or selecting the ideal panel model?
Contact Beyond Green Solar today, and our experts will guide you through the process to ensure your system runs smoothly and efficiently.
