SolaX 3 Phase Inverter (8kW–30kW)

SolaX 3 phase Inverter 8KW-30KW for solar systems in Karachi

Smart Performance. Built for Real Homes and Businesses.

The SolaX X3-PRO G2 is a three-phase inverter series designed to work harder and last longer. With models ranging from 8kW to 30kW, this inverter brings strong efficiency, better control, and smarter energy use—whether you’re powering a home, an office, or a small business.

Why Choose the X3-PRO G2 Series?

High Power, Low Waste

  • Models available in 8kW to 30kW
  • Efficiency rating up to 98.5%
  • Starts up with low voltage and handles a wide MPPT voltage range
  • Supports 150% DC oversizing and 110% AC overloading
  • Built-in MPP scan helps maximize power generation even during weak sunlight

Safety Comes First

  • Built-in surge protection (Type II) on both AC and DC sides
  • Optional arc-fault protection for added peace of mind
  • Fully sealed with an IP66 waterproof rating
  • Smart fault detection and over-temperature protection included

Smarter Energy Control

  • Supports export control and intelligent load management (heat pump-ready)
  • Real-time monitoring through app, LAN, WiFi, or 4G
  • Compatible with master/slave setup for large-scale systems
  • Up to 3 MPPT trackers and 2 strings per tracker—ideal for complex rooftops

Designed to Save Space and Money

  • Compact build with high power density
  • Handles up to 32A DC input per MPPT—great for newer high-power solar panels
  • Minimal night consumption, meaning it quietly saves energy when idle

Key Electrical Specs (12kW Model)

Feature

Specification

Max PV Input Power

18,000W

Max PV Voltage

1100V

Startup Voltage

200V

MPPT Voltage Range

160–980V

MPPTs / Strings

2 MPPTs / 2 Strings per MPPT

Max Input Current

32A per MPPT

AC Output Power

12,000W

Max AC Output Power

13,200VA

Max Efficiency

98.5%

Euro Efficiency

98.0%

Power Factor

0.8 leading to 0.8 lagging

Output Voltage

230/400V (3-phase)

Frequency

50/60Hz

Built for Tough Conditions

Feature

Details

Dimensions

482 × 417 × 186 mm

Weight

24.5 kg

Operating Temp

–30°C to +60°C

Humidity

0–100%

Altitude

Up to 4000 meters

Cooling

Natural convection (no fan noise)

Protection Rating

IP66 (weatherproof)

Communication

USB, RS485, DRM, WiFi, LAN, 4G

Display

LCD with LEDs or app-based interface

Simple Maintenance Tips

Install it right

Choose a cool, dry, and shaded location if possible. Avoid direct sunlight and give space around it for ventilation.

Check the app once in a while

With built-in monitoring tools, you can track performance on your phone and spot any issues early.

Clean occasionally

If the unit gets dusty or dirty, wipe it with a dry, soft cloth. Don’t use water or chemicals.

Yearly inspection helps

A quick look from a certified technician every year can keep it running at peak performance and prevent future trouble.

Planning a New Solar System?

The X3-PRO G2 series works well with both modern high-output panels and energy storage systems. Whether you want backup power, more control over your usage, or better returns from your solar investment, this inverter fits right in.

Need help deciding which size works best?

Our team at Beyond Green Solar is ready to help you pick the right model based on your home, energy use, and budget.

Contact us today for a full solar package that works for you—not just on paper, but in real life.
